Appliance 5000W Household Pure Sine Wave Inverter 12V 48V 12V Off Grid 100V 120V 220V 60Hz Reliable 50Hz 5000 Watt Power Efficient Inverter

1 Piece
MOQ
$312.23(1 - 10 Pieces) $303.22(11 - 50 Pieces) $292.53(51 - 200 Pieces) $277.87(>=201 Pieces)
prezzo
Appliance 5000W Household Pure Sine Wave Inverter 12V 48V 12V Off Grid 100V 120V 220V 60Hz Reliable 50Hz 5000 Watt Power Efficient Inverter
Caratteristiche Galleria Descrizione di prodotto Richieda una citazione
Caratteristiche
Specificazioni
Network: Off-grid
Customized support: Input/output voltage, Socket type
Model Number: TP-5000W-A
Type: DC/AC Inverters
Output Type: Single
Output Current: Load
Output Frequency: 50HZ or 60HZ
Size: 505*205*165mm
Weight: 13kg
Certificate: CE ROHS, CE ROHS
Product name: Pure Sine Wave Inverter
Protection: Overload
Application: Home Appliance
Warranty: 12 Months
Output waveform: Pure Sine Wave Output
Shell material: Aluminum alloy
USB Output: 5V 2.1A
OEM: Accepted
Informazioni di base
Certificazione: CE ROHS, CE ROHS
Model Number: TP-5000W-A
Termini di pagamento e spedizione
Packaging Details: CARTON+BOX Neutral packing
Descrizione di prodotto

5000W Pure Sine Wave Inverter 12V 48V 12 V Off Grid 100V 120V 220V Reliable 60Hz 50Hz 5000 Watt Efficient Power Inverter



Detailed Images



Product Description



The inverter converts DC power (battery, battery) into alternating current (typically 220V, 50Hz sine wave). It consists of an inverter bridge, control logic and filter circuits. The pure positive sleek inverter is suitable for any inductive load and resistive load. The inductive load includes various equipments with AC motor, refrigerator, washing machine, etc.





Specifications



Technical Parameters for 5000W-A Pure Sine Wave Inverter
Model TP-5000W-12V TP-5000W-24V TP-5000W-48V
Rated power 5000W
Peak power 10000W
Input voltage(Range) DC12V(9-15.5V) DC24V(18-31V) DC48V(38-61V)
Output voltage(Single) (100VAC/110VAC/120VAC/220VAC/230VAC/240VAC)±5%
Unload current less than ≤1.2A ≤0.6A ≤0.3A
Output frequency 50Hz or 60Hz
Output waveform Pure Sine Wave
Waveform distortion THD≤3%(Pure resistive Load))
USB 5V,2.1A /
Max.efficiency 90%
Low voltage protection Pre-alarm (alarm off after 1 sound), LED Red light on, voltage contiously reduce and shutdown
Over voltage protection  Pre-alarm (alarm off after 2 sounds), LED Red light on,  shutdown
Over load protection Continuous alarm, LED Red light on, shutdown
Over temperature protection Pre-alarm (alarm off after 3 sounds), tempurature continously rise, LED Red light on, shutdown
Short circuit protection Perfect protection and no damage the circuit
Input reverse polarity protection Fuse burn-out
Low voltage alarm 10.5±0.5V 21±0.5V 42±1V
Low voltage protection 9.5±0.5V 19±0.5V 38±1V
Over voltage protection 15.5±0.5V 31±0.5V 61±1V
Low voltage recover 13±0.5V 24±0.5V 48±1V
Over voltage recover 14V±0.2V 28V±0.5V 54V±1V
Working temperature -10°- +50°
Product Dimension(mm) 505*205*165
Mounting Size(mm) 475*130
Product Lable Size(mm)
Packing(mm) 555*267*210
Net./gross weight(g) 10000/11700
QTY/CTN 2 PCS
Meas./CTN(mm)
Gross weight/CTN(g) 25000
Warranty 12Months
DC Cable(mm²)
Spare Fuse
Cooling method Intelligent air cooling
Note: Our products update constantly.The technical parameter is for reference only.Please refer to our real product.

Product Dimension:





 Packaging

Product Uses



Application:

Pure sine wave inverters are widely used in various types: microcomputer systems, communication systems, home, aviation, emergency, communications, industrial equipment, satellite communications equipment, military vehicles, medical ambulances, police vehicles, ships, solar and wind power generation, etc. A place where emergency backup power is required may constitute an EPS emergency power supply system.

Factory Show



Certifications

FAQ

 FAQ:

Q1. Do you test all your goods before delivery?

A: Yes, we have 100% test before delivery



Q2. Can you produce according to the samples?

A: Yes, we can produce by your samples or technical drawings. We can build the molds and fixtures.



Q3. How about your delivery time?

A: Generally, it will take 10 to 30 days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.



Q4. What is your sample policy?

A: We can supply the sample if we have ready parts in stock, but the customers have to pay the sample cost and the courier cost.



Q5:What is a resistive load appliances?
A:Generally speaking, appliances like mobile phones, computers, LCD TVs, incandescents, electric fans, video broadcast, small printers, electric mahjong machines, rice cookers etc. All belong to resistive loads. Our modified sine wave inverters can drive them successfully.



Q6:What is the inductive load appliances?
A:It refers to the application of electromagnetic induction’s principle, produced by high-power electrical products, such as motor type, compressors, relays, fluorescent lamps, electric stove, refrigerator, air conditioner, energy saving lamps, pumps, etc. These products’power are far more than the rated power (about 3-7 times) when start. So only pure sine wave inverter is available to them.



Q7:What should be noticed when installing inverter?
A:Put the product in a place where is well ventilate,cool, dry and water-proof. Pls do not stress and do not put foreign objects into the inverter.Rember to turn on the inverter before turn on the appliance.



Q8: How do you make our business long-term and good relationship?

A:1. We keep good quality and competitive price to ensure our customers' benefit;

2. We respect every customer as our friend and we sincerely do business and make friends with them, no matter where they come from.
